Taiyo Cabletec Co., Ltd. CM/2464-1007/ⅡA LF
CM/2464-1007/ⅡA LF is a multi-core fixed wiring cable for electronic devices, ideal for control and communication signals such as RS232C. It uses stranded tinned soft copper conductors, heat-resistant PVC insulation, and a black PVC sheath that offers oil resistance, heat resistance, and flexibility. Certified under UL AWM STYLE 2464 and CM listing, and also serves as an alternative to CL3/CL3X. It conforms to NFPA 70/79 and is rated at 300V and 80°C (AWM). It also passes UL VW-1, CUL FT1, and vertical tray flame tests, and complies with the RoHS Directive (10 substances). The “R15” marking indicates RoHS compliance.
Product Features
- Application: Multi-core cable for fixed wiring of RS232C and control signals
• Flexibility: Flexible PVC makes it ideal for internal wiring with easy routing
• Durability: Stable structure suitable for long-term fixed wiring use
• Environmental Resistance:
– Heat Resistance: Rated to 80°C (AWM), 75°C (CM)
– Oil Resistance: Industrial-grade high oil-resistant PVC sheath
– Flame Retardance: UL VW-1 / CUL FT1 compliant, vertical tray flame test passed
– Noise Resistance: Tape structure provides noise suppression
– Low Migration: Low plasticizer migration prevents adverse effects on nearby devices
• Safety: RoHS compliant (2011/65/EU・2015/863), R15 marking
Product Specifications
- Certifications: UL (CM, AWM 2464), CUL (CM, AWM ⅡA), CSA certified
• Standards Compliance:
– UL 758 (AWM), UL 444 (CM), UL 13 (CL3 alternative)
– CSA C22.2 No.210 / No.214
– NFPA 70 / 79, RoHS 2011/65/EU・2015/863
• Ratings:
– Voltage: 300V
– Temperature: 80°C (AWM), 75°C (CM)
• Flame Retardant Standards:
– UL VW-1 (U.S.)
– CUL FT1 (Canada)
– UL vertical tray test passed
• Standard Length: 100m
• Conductor Sizes/Types: 2C–30C, supports AWG22–16
