Taiyo Cabletec Co., Ltd. Hyper Soft (HPF) #600SB LF
Hyper Soft (HPF) #600SB LF is a flexible shielded cabtire cable for power/control circuits up to 600V, ideal for environments requiring resistance to oil, heat, and noise. It uses stranded annealed copper conductors, heat-resistant PVC insulation, and a matte black oil/heat-resistant flexible PVC sheath. A braided tinned copper wire shield with drain wire enhances noise immunity. Rated at 600V / 75°C, it complies with the Electrical Appliance and Material Safety Act, JIS C 3102 & C 3005 (flame retardant), and is CMJ-registered with F mark. RoHS compliant (10 substances), with “R15” marking.
Product Features
- Application: For fixed power/control wiring in machine tools, control panels, and equipment requiring noise protection
• Flexibility: Easy handling with stranded conductor and soft PVC sheath
• Durability: Excellent long-term performance under oil/heat exposure
• Environmental Resistance:
– Heat: Rated up to 75°C
– Oil: Cutting/hydraulic oil resistance rated A–B
– Flame Retardance: JIS C 3005 compliant, CMJ vertical flame test passed (F mark)
– Noise: Braided shield + drain wire provides superior shielding
– Non-Migration: No plasticizer migration, safe for ABS/PS resins
• Safety: RoHS compliant (2011/65/EU・2015/863), R15 printed
Product Specifications
- Certifications: Electrical Appliance and Material Safety Act (PSE), CMJ (F mark)
• Standards Compliance:
– JIS C 3102 (conductor), JIS C 3005 (flame retardant)
– RoHS 2011/65/EU・2015/863 (10 substances)
• Ratings:
– Voltage: 600V
– Temperature: 75°C
• Flame Standard:
– JIS C 3005 (4.26.2 b)
– CMJ vertical flame test passed (F mark)
• Others:
– Sizes: 0.75–14 mm², 2C–4C
– Surface Marking Example: “○○mm² Hyper Soft #600SB Oil/Heat Resistant TEIKOKU <PS>E LFV R15 -F-”
– Standard Length: 100m / 500m (cutting available by size)
– Current: Based on JCS0168, 30°C ambient reference with correction factors
