Taiyo Cabletec Co., Ltd. FAFX-5E25SLAB (BK)
2026.05.17
FAFX-5E25SLAB (BK) is a CAT5e-compliant, high-flex, high-shield Ethernet cable with a dual-shielded structure. It uses 7/0.18mm stranded soft copper wires as conductors, PE for insulation, and oil-, heat-, and flame-resistant flexible PVC for the sheath. The shield structure consists of aluminum-laminated PET tape and tin-plated copper braid, enhancing noise resistance. Compliant with UL STYLE 20276, CUL FT1, CSA standards, rated for 30V and 80°C. Also compatible with CC-Link IE, EtherCAT, and RoHS Directive.
Product Features
- Application: CAT5e-compliant Ethernet wiring requiring flexing and motion
• Flexibility: Ultra-fine conductors and flexible sheath ensure excellent routing performance
• Durability: High-flex design supports movable applications
• Environmental Resistance:
– Heat Resistance: Up to 80°C
– Oil Resistance: Oil-resistant PVC sheath
– Flame Retardance: Conforms to UL VW-1 / CUL FT1
– Noise Resistance: Dual shield structure (aluminum tape + braid)
• Other: Complies with CAT5e, CC-Link IE, EtherCAT; RoHS compliant (R15 marking); standard length 200m
• Safety: RoHS compliant (2011/65/EU・2015/863) for 10 substances
Product Specifications
- Certifications: UL, CUL, CSA certified
• Standards Compliance:
– UL AWM STYLE 20276 (U.S. standard)
– CSA C22.2 No.210 (Canadian standard)
– RoHS 2011/65/EU, 2015/863 (environmental regulation)
• Ratings:
– Voltage: 30V
– Temperature: 80°C
• Flame Retardant Standards:
– UL VW-1 (U.S. flame test)
– CUL FT1 (Canadian flame test)
