Taiyo Cabletec Co., Ltd. FAFXQ-5E22SLAB/CM (BU)
2026.05.17
FAFXQ-5E22SLAB/CM (BU) is a CAT5e-compliant, quad-type industrial Ethernet cable with high flexibility and dual shielding, compatible with Mechatrolink-III/IV and EtherCAT. It features 7/0.26mm stranded conductors, PE insulation, and a light blue flexible PVC sheath with oil, heat, and flame resistance. The dual-shield construction (aluminum tape + braid) provides excellent noise immunity. It conforms to UL STYLE 20276, CM listing, CUL, and CSA standards, rated at 300V and 75°C. RoHS-compliant (10 substances).
Product Features
- Application: Flexible control and communication wiring (CAT5e)
• Communication Standards: CAT5e, Mechatrolink-III / IV, EtherCAT compliant
• Flexibility: 7/0.26mm stranded conductors + flexible PVC for high bendability
• Durability: Optimized for wiring with movement or bending
• Environmental Resistance:
– Heat Resistance: Supports up to 75°C
– Oil Resistance: Uses oil-resistant PVC sheath
– Flame Retardance: UL VW-1 / CUL FT1, passed vertical tray test
– Noise Resistance: Dual shielding with aluminum tape + braid
• Other: Light blue sheath (other colors available), length markings, RoHS (R15) compliant
Product Specifications
- Certifications: UL, CUL, CSA, CM listing certified
• Standards Compliance:
– UL STYLE 20276 (AWM), UL 444 (CM)
– CSA C22.2 No.210 / No.214
– RoHS 2011/65/EU, 2015/863 (10 substances)
• Ratings:
– Voltage: 300V
– Temperature: 75°C (CM), 80°C (AWM)
• Flame Retardant Standards:
– UL VW-1 (U.S.)
– CUL FT1 (Canada)
